Compare

  • Overall dimensions
  • Weight
  • Touchscreen display
  • Waveform memory
  • Maximum cable length
  • Tracker Pro
  • 9.1" x 7.5" x 4.3"
  • 3 lbs. 10 oz.
  • 7" Color LCD
  • 60 multi-pulse
  • 15,965 ft.
  • Tracker
  • 9.3" x 5.5" x 2.6"
  • 2 lbs. 10 oz.
  • 5" Color LCD
  • 10 multi-pulse
  • 2,000 ft.
  • Tracker Jr
  • 7.5" x 5.0" x 2.1"
  • 1 lbs. 10 oz.
  • 4.3" Color LCD
  • 1
  • 500 ft.

Technical specifications

Tracker Pro

  • 7" LCD color touchscreen display (800 x 480)
  • 60 multi-pulse waveform memory
  • Multiple marking and measurement cursors
  • Splashproof USB connection
  • Bluetooth 4.0
  • 4200 mAh nickel-metal- hydride battery
  • 14 bits
    • Dimensions:
    • 9.12” x 7.56” x 4.37”
    • Weight:
    • 3 lbs 10 oz
    • Pulse widths:
    • 2 nsec, 5 nsec, 20 nsec, 50 nsec, 100 nsec, 500 nsec
    • Max cable length:
    • 15,965.18 ft @ 85% VOP
    • Signal filtering:
    • 1, 2, 4, 8, 16, 32, 64
    • Operating temperature:
    • 0º C - 50º C (32º F - 122º F)
    • Storage temperature:
    • -20º C - 60º C (-4º F - 140º F)
    • Humidity:
    • 95% maximum relative, non-condensing
    • Horizontal resolution:
    • 0.1 foot
    • Vertical resolution:
    • 14 bit analog to digital conversion
    • Distance accuracy:
    • 0.44 feet @ 99% VOP, 0.38 feet @ 85% VOP, 0.18 feet @ 40% VOP
    • Input protection:
    • AC Power Filtering,
      400 V (AC + DC)
      from DC to 400 Hz
      decreasing to 10 V
      at 1 MHz

Tracker

  • 5” LCD color touchscreen display (800 x 480)
  • 10 multi-pulse waveform memory
  • Splashproof USB connection
  • Bluetooth 4.0
  • 2100 mAh nickel-metal- hydride battery
  • 14 bits
    • Dimensions:
    • 9.37” x 5.56” x 2.62”
    • Weight:
    • 2 lbs 10 oz
    • Pulse widths:
    • 5 nsec, 20 nsec
    • Max cable length:
    • 2,000 ft
    • Signal filtering:
    • 1, 2
    • Operating temperature:
    • 0º C - 50º C (32º F - 122º F)
    • Storage temperature:
    • -20º C - 60º C (-4º F - 140º F)
    • Humidity:
    • 95% maximum relative, non-condensing
    • Horizontal resolution:
    • 0.1 foot
    • Vertical resolution:
    • 14 bit analog to digital conversion
    • Distance accuracy:
    • 0.44 feet @ 99% VOP, 0.38 feet @ 85% VOP, 0.18 feet @ 40% VOP
    • Input protection:
    • AC Power Protection,
      400 V (AC + DC)
      from DC to 400 Hz
      decreasing to 10 V
      at 1 MHz

Tracker Jr

  • 4.3” LCD color touchscreen display (480x272)
  • 1 waveform memory
  • Splashproof USB connection
  • Bluetooth 4.0
  • 700 mAh nickel-metal-hydride battery
  • 14 bits
    • Dimensions:
    • 7.50” x 5.06” x 2.12”
    • Weight:
    • 1 lbs 10 oz
    • Pulse widths:
    • 5 nsec
    • Max cable length:
    • 500 ft
    • Signal filtering:
    • 1
    • Operating temperature:
    • 0º C - 50º C (32º F - 122º F)
    • Storage temperature:
    • -20º C - 60º C (-4º F - 140º F)
    • Humidity:
    • 95% maximum relative, non-condensing
    • Horizontal resolution:
    • 0.1 foot
    • Vertical resolution:
    • 14 bit analog to digital conversion
    • Distance accuracy:
    • 0.44 feet @ 99% VOP, 0.38 feet @ 85% VOP, 0.18 feet @ 40% VOP
    • Input protection:
    • AC Power Protection,
      400 V (AC + DC)
      from DC to 400 Hz
      decreasing to 10 V
      at 1 MHz
